广州美国UE授权代理 J120-701-1010 双刀双掷DPDT 防爆开关 压力

美国UE J120系列部分产品型号及技术参数：
型号                  可调整设定范围                          死区                         zui大压力                   耐压**
Model       Adjustable Set Point Range            Deadband                  Over Range                Proof
         Low end of range on fall;                                                    Pressure*                Pressure**
                High end of range on rise
              psi          bar (unless noted)         psi                 mbar                 psi          bar          psi       bar
Buna N diaphragm and O-Ring with nickel-plated brass 1/4” NPT (female) pressure connection; Optional Viton diaphragm and O-Ring available
701  1.5 to 30        103,4 mbar to 2,1       1 to 2 68,9 mbar to 0,1 500 34,5 600 41,4
702  3 to 100         0,2 to 6,9                    1 to 4         68,9 mbar to 0,3    500         34,5        600     41,4
703  9 to 300         0,6 to 20,7                  1 to 5         68,0 mbar to 0,3    500         34,5        600     41,4
704  15 to 500       1,0 to 34,5                  2 to 8         0,1 to 0,6               1500       34,5        600     41,4
705  30 to 1000     2,1 to 68,9                  3 to 20       0,2 to 1,4               1500       34,5        600     41,4
